MikroTik Cloud Router Switch CRS326-4C+20G+2Q+RM 650MHz 2x 40 Gbps QSFP+ 20x 25 Gbps LAN 4x Combo L6 2x PSU1U
MIKROTIK | CRS326-4C+20G+2Q+RM | 4752224008930
Out of stock.
Price of goods is 869.48 €.
Weight of goods is 3.92 Kg.
Actual in cart 0 pcs.
MikroTik CRS326-4C+20G+2Q+RM
Cloud Router Switch with 20× 2.5Gbit RJ-45, 4× Combo 10Gbit RJ-45/SFP+, 2× 40Gbit QSFP+ and two RJ-45 ports (management and console) is an ideal solution for both Internet providers , as well as for companies. A big advantage is the dual system RouterOS / SwitchOS (License level 6). The Cloud Router Switch is in 1U design, so it can be mounted directly in a rack.
The RouterBoard includes MikroTik RouterOS/SwitchOS and a full L6\ license. The package includes a power cable and L profiles for rack mounting.
Information about RouterOS MikroTik
- All RouterBoards have the same RouterOS MikroTik system.
- All devices with RouterOS MikroTik fully support IPv6, have firewall, Queues, NAT and with L4 license support CAPsMAN server.
- MikroTik can be set up via the web interface, via the mobile application, or the winbox program, which can be downloaded from mikrotik.com.
- MikroTik has "Quick Set" ie quick setting option. There are several preset profiles to choose from.
Ports
- 20× 2.5Gbit SFP+
- 4x 10Gbit RJ-45/SFP+
- 2x 40Gbit QSFP+
- 2x RJ-45 port (console and management/boot
Operating System: MikroTik RouterOS or SwitchOS (L6)
Switch capacity: 340 Gbps
PoE support: no
Max. power consumption: 70 W
Dimensions: 443 x 258 x 44 mm
| Name | Value | |
|---|---|---|
| Input voltage [V] | 100 - 240 (AC) | |
| Color | white | |
| Dimension [mm] | 443 × 258 × 44 mm | |
| Minimum operating temperature [°C] | -20 | |
| Maximum operating temperature [°C] | 60 | |
| DHCP | Yes | |
| RJ-45 console management | 2 | |
| MicroSD card support | No | |
| Processor | Atheros QCA9531, 650 MHz | |
| QSFP+ count | 1 | |
| NAND [MB] | 32 | |
| Memory size [MB] | 128 | |
| SFP+ count | 4 | |
| Chipset | Atheros QCA9531 | |
| Port speed | 2,5 Gb/s + 10 Gb/s + 40 Gb/s | |
| Management | Yes | |
| Device power supply | redundant | |
| Bus capacity (GBps) [Gbps] | 340 | |
| Design | rack 19" | |
| OSI Layer | L3 dynamic | |
| RS-232 port | No | |
