Planet dual 5G LTE security gateway 2x WAN + 3x LAN DI TO GPS DIN IP30 -40 +75°C dual 9-54VDC

PLANET ICG-2515-NR

Industrial security gateway 5G/LTE IoT/M2M infrastructure (machine-to-machine), 3x LAN, 1x LAN/WAN, 1x WAN), 1x RJ-45 serial port (DB9), 2x SIM slot ( redundant), 2x DI digital input, 2x DO digital output, 4x 5G NR antenna (SMA connectors, 5 dBi gain, 3G/4G/LTE/5G mobile networks), download up to 2.4 Gbps , upload up to 500 Mbps, GNSS (GPS L1+L5, GLONASS, BeiDou, Galileo, QZSS). Web/SNMP v1/v2c/v3 management, SSH v2, TLS v1.2, UNI-NMS support and PLANET Smart Discovery utility and Planet CloudViewer App, router with firewall, VPN support, dual WAN, RADIUS Server/Client, protection IP30, working temperature -40 to +75 °C, DIN rail mounting, power supply DC 9-54 V.

Industrial Ethernet 5G/LTE gateway for possible application within IoT (Internet of Things) networks, M2M (machine to machine) industrial automation, but also for normal internet connection in mobile devices. A gateway can become a robust element of your customer's data network infrastructure.

The basic communication interface is a 5G NR (NSA/SA) interface with backward support for networks of previous generations (4G/LTE/3G), which you can use for places with poor signal coverage, while moving or roaming. In addition to the gateway function, this device is also equipped with a cable router function through RJ-45 connectors. Thanks to this, the device is also ready for use with a classic cable connection if this installation is necessary. Planet's industrial elements are easily installed on a standard DIN rail or directly on the wall and enable the deployment of the well-known Ethernet technology even in an industrial environment.

Key properties

• Global 5G NR (NSA/SA) and 4G LTE network with two SIM slots for mobile network redundancy & Siemens SIMCom 4G/5G hardware modem
• Dual WAN - switching services in case of failure and load balancing (Load Balance)
• Automatic failover between 5G NR and Gigabit WAN
• 2x DI/DO and 1x serial port (RS-485) for Modbus applications
• GNSS localization in space with GPS/GLONASS/BeiDou/Galileo/QZSS support
• High availability HA (High Availability)
• SSL VPN and robust hybrid VPN (IPSec/PPTP/L2TP over IPSec)
• Firewall with stateful packet inspection (SPI) + content filtering
• Advanced blocking of DoS/DDOS attacks
• Routing port ranges
• AP controller - access interface (Captive Portal) including RADIUS - management of up to 16 AP Wi-Fi units without the need to purchase a license
• Support for Planet NMS and CloudViewer control systems
• Operating temperature -45 to +75 °C, DIN rail design, fanless

Norms and standards

• EN 301 908 - IMT cellular networks and access to them
• EN 303 413 - Satellite Earth Stations and Systems (SES)
• EN 301 489 - Electromagnetic compatibility (EMC) and radio spectrum matters (ERM) of radio equipment and services
• EN 62311:2008 - Assessment of equipment in relation to limitations of human exposure to electromagnetic fields (0 Hz - 300 GHz)
• EN IEC 62368-1:2020/A11:2020 - Audio/video, information and communication technology equipment

Ports

• 3x GbE RJ-45 LAN
• 1x GbE RJ-45 LAN/WAN
• 1x GbE RJ-45 WAN
• 1x RJ-45 serial port
• 2x SIM slot
• 2x DI digital input
• 2x digital output D

Mobile connection

• 5G-NR (New radio)
• 2x SIM slot
• 4x SMA connector

High Availability: Automatic failover between 5G NR and Gigabit WAN

MODBUS support: yes

Memory

• Flash 16MB
• 32 GB eMMC
• 512 MB of RAM

IP protocol version

• IPv4
• IPv6

Execution

• DIN rail
• on the wall

Power supply

• 2x DC 9-54 V
• total power consumption up to 7 W (source not included in the package)
• the power inputs are mutually backed up

LED indication of mobile signal status and strength: yes

Operating temperature

• -40 to +75 °C
• humidity up to 90%

Dimensions: 135 x 135 x 50 mm

Weight: 0.8 kg

Supported LTE bands and frequencies

• 5G NR: n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/n38/n40/n41/n48/n66/n71/n77/n78/n79
• LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29/B30/B32/B46 /B66/B71
• LTE TDD: B34/B38/B39/B40/B41/B42/B43/B48
• WCDMA: B1/B2/B3/B4/B5/B8

GNSS (positioning systems supported)

• GPS L1+L5 (dual-band)
• GLONASS
• BeiDou
• Galileo
• QZSSS

Administration

• Web
• SNMP v1/v2c/v3
• SSH v2
• TLS v1.2
• UNI-NMS controller support
• Smart Discovery utility and Planet CloudViewer application

Network security

• Cybersecurity
• Firewall
• Sleep
• blocking of DoS/DDoS attacks
• content filtering
• MAC/IP filter
• NAT ALGs
• blocking of SYN/ICMP Flooding

Routing

• static
• dynamic
• OSPF

Wi-Fi support

• controller for Wi-Fi AP units Planet
• Captive portal
• built-in hostpot function for Wi-Fi clients

DHPC server: yes

Radius server/client: yes

VPN support

• max. 60 tunnels
• max 60 Mbps
• hybrid
• IPSec/Remote Server (Net-to-Net
• Host-to-Net)
• GRE
• PPTP Server
• L2TP Server
• SSL Server/Client (Open VPN
