Teltonika industrial unmanaged switch on DIN rail TSW304 4port 10 100 1000M
TELTONIKA | TSW304 00B000 | 4779051840144
Out of stock.
Price of goods is 105.42 €.
Weight of goods is 0.268 Kg.
Actual in cart 0 pcs.
Teltonics TSW304
Industrial gigabit switch without management offering four RJ-45 ports. Easy to use with no configuration or installation required. The Switch has a built-in DIN rail mount. Switching capacity reaches up to 8 Gbps. The buffer has a capacity of 128 KB, the table of MAC addresses is 2K, and Jumbo frames of 9 KB are supported.
- High-end device with integrated DIN holder (no additional accessories required).
- Resistance to voltage fluctuations.
- DC and AC power supply.
- Ideal for applications with limited space.
Number of ports: 4x RJ-45 10/100/1000 Mb/
PoE: no
Switch capacity: 8 Gbps
Power supply: DC 7-57V or AC 9-40V (power adapter not included)
Dimensions: 102 x 81.5 x 25 mm
| Name | Value | |
|---|---|---|
| Input voltage [V] | 9 - 40 (AC) | |
| Color | black | |
| Dimension [mm] | 102 × 81,5 × 25 mm | |
| Minimum operating temperature [°C] | -40 | |
| Maximum operating temperature [°C] | 75 | |
| LAN | Yes | |
| MicroSD card support | No | |
| Degree of coverage | IP30 | |
| Management | No | |
| Port speed | 1 Gb/s | |
| Bus capacity (GBps) [Gbps] | 8 | |
| Fanless | Yes | |
| Design | DIN rail | |
| Device power supply | external adapter | |
| OSI Layer | L2 | |
