TP-Link Archer AX90 AX6600 router 3x GLAN 2x GWAN 802.11a b g n ac ax

TP-Link Archer AX90

Tri-band gigabit router working in 2.4 and 2x 5 GHz bands with support for 802.11a/b/g/n/ac/ax standards. The Archer AX90 router provides eight simultaneous data streams by combining a tri-band Wi-Fi network with cutting-edge Wi-Fi 6 technology, making more bandwidth available and allowing connected devices to operate at full speed. Eight high-gain antennas transmit a stronger Wi-Fi network signal to every corner of your home and have an aesthetic appearance. In the 2.4 GHz band, it reaches transmission speeds of up to 574 Mbps and in the 5 GHz band up to 4804 Mbps + 1201 Mbps. For easy setup and use, you can use the Tether mobile app or the web interface.

• Faster tri-band Wi-Fi network with AX6600 - 4804 Mbit/s (5 GHz), 1201 Mbit/s (5 GHz), 574 Mbit/s (2.4 GHz).
• Wide range of connections - 1 2.5 Gbit/s WAN/LAN port + 1 1 Gbit/s WAN/LAN port + 3 gigabit LAN ports and two USB ports ensure maximum flexibility and increased throughput.
• Maximum signal coverage - Eight high-gain antennas equipped with Beamforming technology provide very wide coverage.
• More connected devices with less latency - OFDMA and MU-MIMO technologies direct data streams to multiple devices simultaneously.
• TP-Link HomeShield - Enhanced security to protect against the latest cyber threats.
• Powerful processor - 1.5GHz quad-core processor ensures fast transfer speeds and smooth operation when using more devices and applications.
• More Perfect Security - The WPA3 protocol provides more robust Wi-Fi encryption, increasing network security.

Beamforming

• Beamforming technology and 6 high-gain antennas combine to create a strong and reliable Wi-Fi signal throughout the home, providing a smooth and stable connection for every client.

OFDMA technology

• Add more Wi-Fi devices without degrading performance. OFDMA allows multiple devices to use one band at the same time, so your Wi-Fi can support more devices compared to the same speed of a Wi-Fi 5 router.

Standard: 802.11a/b/g/n/ac/ax

Data transfer speed

• 4804 Mbps - 5 GHz
• 1201 Mbps - 5 GHz
• 574 Mbps - 2.4 GHz

Antenna: 8 x external omnidirectional antenna

Ports

• 1 x 2.5 GbE RJ-45 LAN/WAN
• 1 x RJ-45 LAN/WAN
• 3 x RJ-45 LAN
• 1 x USB 2.0
• 1 x USB 3.0

Frequency band

• 2.4 GHz
• 5 GHz

Security

• WPA
• WPA2
• WPA3
• WPA/WPA2-Enterprise (802.1x)

PoE support: no

Dimensions: 311 x 207 x 174 mm
