TP-Link CPE510 - Outdoor CPE device 5 GHz 300 Mbit with 13dBi
TP-Link | CPE510 | 6935364070922
On stock 1 pcs.
Price of goods is 57.16 €.
Weight of goods is 0.907 Kg.
Actual in cart 0 pcs.
TP-Link CPE510
Outdoor CPE equipment designed for economical outdoor wireless network solutions. Its centralized management system makes it ideal for point-to-point, point-to-multipoint and outdoor wireless network coverage. Professional performance combined with a user-friendly design make the CPE510 an ideal choice for work and home use.
Hardware for business solutions
With the Qualcomm Atheros chipset, high-gain antennas and high-quality material used, specially designed housing and PoE power supply, the CPE510 is primarily designed for outdoor use and can work flawlessly in almost any climate, with an operating temperature ranging from -30°C to +70 °C.
Advanced antenna system
Built-in high gain dual polarized antenna.
Wireless data transmission up to a distance of 15 km+
Specially designed for outdoor use, ideal for long distance wireless data transmission.
TP-LINK MAXtream TDMA technology
Due to the ever-increasing network scale, the mutual interference and collision of wireless networks between CPE devices and base stations will be so great that the actual network throughput will decrease, which will be felt very negatively by the end users. To mitigate these negative effects, the CPE510 uses MAXtream TDMA technology.
Pharos Management - Centralized management system
The device is equipped with centralized management software that helps users easily manage all devices on their network from a single computer. Functions such as device discovery, health monitoring, firmware updates and network maintenance can be managed using Pharos control.
Supported standards: IEEE 802.11a/n
Frequency range: 5.15 - 5.85 GHz
Gain: 13 dBi
Memory
- 64 MB DDR2 RAM
- 8 MB Flash
PoE
- Yes
- passive PoE
Dimensions: 224 x 79 x 60 mm
| Name | Value | |
|---|---|---|
| Color | white | |
| Dimension [mm] | 224 × 79 × 60 mm | |
| Minimum operating temperature [°C] | -40 | |
| Maximum operating temperature [°C] | 70 | |
| Wi-Fi standard | 802.11a/n | |
| Indoor use | No | |
| Height [mm] | 60 | |
| Width [mm] | 224 | |
| Operating mode | AP, Client, Repeater, Router | |
| Depth [mm] | 79 | |
| DHCP | Yes | |
| Conformity | CE, FCC, RoHS, IPX5 | |
| Power supply [V] | 16 - 27 | |
| Encryption | 64/128/152-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (AES-TKIP) | |
| Wi-Fi frequency | 5150 - 5850 MHz | |
| Antenna design | internal | |
| Max. output power [dBm] | 23 | |
| Transmission speed [Mbps] | 300 | |
| Port speed | 100 Mb/s | |
| MicroSD card support | No | |
