XtendLan mini GBIC SFP LC 1000Base-LX 3km WDM TX1550nm RX1310nm Cisco Planet compatible
XTENDLAN Consumer | XL-MGB-LXBE-LC | 8592457134732
On stock 128 pcs.
Price of goods is 12.73 €.
Weight of goods is 0.023 Kg.
Actual in cart 0 pcs.
XtendLan MGB-LXBE-LC
Gigabit miniGBIC module (SFP), 1000Base-LX, simplex LC connector, single-mode, WDM. Range 3-10km. TX 1550nm/RX 1310nm. Support of most manufacturers (Cisco, Dell, Planet, ...)
Small-Form-Pluggable (SFP) miniGBIC conversion Gigabit module. Standard 1000Base-LX, IEEE82.3z. Simplex LC connector, for single-mode fibers. It enables two-way communication over a single optical fiber.
Expands/converts switch and converter ports with miniGBIC (SFP) slots. E.g. for GSW-2400, FGSW-4840S, SGSW-2620, WGT/GT-705A, ENW-9607M.
For the connection between WDM modules, it is necessary to combine the TX/RX wavelengths of the opposite sides, pairs of modules are usually distinguished by a code representing the A or B side.
Module type: SFP
Connector: LC simplex
Wavelength (transmitter/receiver): 1550 nm / 1310 nm
Thread Type: Singlemode
Connection range: up to 3 km
Transmission margin: 12 dB
Sensitivity: -21 dBm
Transmission speed: 1.25 Gb/s
| Name | Value | |
|---|---|---|
| Color | silver | |
| Compatibility | Cisco, Dell, Planet and others | |
| SFP module compatibility | DELL | |
| Diagnostics of DDM | No | |
| Transmit wavelength | 1550 nm | |
| SFP module speed | 1,25 Gbps | |
| Range [km] | 3 km | |
| Medium | 1 thread | |
| Optical connector type | LC | |
| Temperature resistance | common | |
| Type of optical fiber | singlemode | |
| Module type | SFP | |
| Design | WDM | |
